Description
DARIMO CARBON Seat Clamp Sub4 | 34.9 mm
With the Sub4 Darimo sets a new standard in terms of weight at a saddle clamp. At just 3.9g at 34.9mm diameter, it lives up to the name Sub4. Each of the clamps is manufactured in elaborate manual work. All inserts for the M5 titanium screw are made of high-strength aluminum and tolerate a torque up to max. 5 nm.
NOTE: The instructions for the product must be observed! Torques must be strictly adhered to. If the necessary expertise or tools for correct installation are missing, the installation must be carried out by a specialist workshop with appropriate knowledge.
Technical specifications:
Material clamp: UD Carbon
Material screw: titanium
Seat tube Ø: 34.9 mm
Overall height: approx. 11 mm
Clamping height: approx. 11 mm
max torque: 5 Nm
Tool holder: 4 mm hexagon socket
Color of the screw: black
Weight: 3.9g
Scope of delivery: DARIMO CARBON Seat Clamp Sub4 | 34.9 mm
