GARBARUK Chainring Melon oval 1-speed oval narrow-wide CX BCD 110

GARBARUK chainring Melon oval 1-way narrow-wide CX LK 110

Garbaruk is a company from Ukraine, which has its roots in motorsport.
The design and manufacture of tuning parts for engines and chassis were part of the Garbaruk company's track horse. The Garbaruk brothers, who are enthusiastic about cycling, incorporate the experience and knowledge they have gained into the production of bicycle parts. All steps from design and production to surface finishing take place under one roof.

7075-T6 aluminum from Germany is the raw material from which the Garbaruk chainrings are elaborately CNC-milled. The chainrings have some features that differ from the competition. In order to keep the chain securely in position even without a chain guide, the teeth have a special profile of narrow and wide teeth alternating. So that this is also given under very rough and rough conditions, the teeth of the Garbaruk chainrings are made approx. 40% longer than normal teeth. Furthermore, the teeth are shaped so that the chainring works very well even in muddy conditions. Dirt and mud are effectively removed when the chain overflows. We recommend the use of a rear derailleur with increased cage tension (Sram Type 2-3, Shimano Shadow +), which holds the chain reliably in position and prevents the chain from jumping off.

The ovalization of the chainring increases the performance by varying the drive train and optimizing the resistance. When you kick your legs, natural strengths and weaknesses are brought into harmony. In this way, better use of the stronger muscle groups is achieved and a balance is created in the weaker muscles on the way to work (lower stroke).

The Garbaruk chainring for compact cranks with 110 millimeter bolt circle diameter diameter is ideally suited to convert a cyclocross bike to a 1-speed drive. With this purpose, the chainring can show its very good self-cleaning and the optimal hold of the chain.


Technical specifications:

Material: 7075-T651 aluminum
Technology: Narrow Wide, Melon (oval)
bolt circle diameter : 110 mm compact (5-hole)
Attachment: 5-arm spider
Number of teeth: 34, 36, 38, 40, 42, 44, 46, 48, 50 or 52
Compatibility cranks : 5-arm compact
Compatibility chain: 9-speed, 10-speed , 11-speed
chain line : n / a
Offset: 2mm (34T), 0mm (36T - 56T)
Adjustment options: none
Range (ovalization): 12%
Timing (force introduction): 108 ° after TDC (OT)
Color: black, red, blue, green, purple, orange

Weights: 48g (34T), 51g (36T), 54g (38T), 60g (40T), 68g (42T), 78g (44T), 90g (46T)


Scope of delivery: 1x GARBARUK chainring Melon oval 1-way narrow-wide CX LK 110
