Description
FSA Headset NO.69 SRS | IS52/28.6 | IS52/40
The FSA NO.69SRS headset is suitable for internal cable routing with exit under the stem. The lower fork cone, like the upper clamping cone, is made of high-quality aluminum. It is a special headset for frames with a continuous 1.5" head tube. It is for tapered steerer tubes with a 1.5" lower diameter / 1 1/8" upper diameter.
SRS - Simple Routing
This system runs your brake lines and Bowden cables completely invisibly through the frame.
Technical specifications:
Material: steel, aluminum
Design: Ahead, IS
Steerer tube: 1 1/8" to 1.5" tapered
SHIS upper part: IS52/28.6
SHIS base: IS52/40
Press-in dimension above Ø: 52 mm
Press-in dimension below Ø: 52 mm
Outer Diameter Top: 55.8mm
Bottom Outer Diameter: 55.8mm
Overall height at top: 10.4 mm
Overall height below: 0.5 mm
Bearing : Angular ball bearing
Colour: silver, matt black
Weight according to the manufacturer: 94g
Weight weighed: 119.1g
Scope of delivery: 1x FSA headset NO.69 SRS | IS52/28.6 | IS52/40
