CARBON-TI Chainring X-CarboRing X-AXS Carbon BCD 110 asymmetric | 33 Teeth inner

Description

CARBON-TI chainring X-CarboRing X-AXS Carbon 4-Arm LK 110 asymmetric | SRM Origin | 33 teeth inner

The new X-CarboRing X-AXS chainrings for the electronic SRAM AXS 12-speed groupsets are made from an optimum mix of materials. The main component is carbon, milled to perfection in Italy, with an aluminum ring (AL7075-T6) and titanium elements (grade 5 titanium) for the shifting aids. This makes the CARBON-TI CarboRing chainring the best example of sensible use of materials in terms of durability and weight.
The back of the carbon chainring is artfully milled to save even the last few grams and enable perfect shifting performance. The use of aluminum as the tooth material ensures durability.
The chainring is designed for SRM Origin 9000 cranks with 4-arm mount and asymmetric 110 mm bolt circle, but can also be fitted to Dura Ace FC-9000 and Ultegra FC-6800 cranks.

Note: For optimum shifting performance, CARBON-TI recommends the use of the matching outer CARBON-TI X-CarboRing X-AXS chainring with 46 teeth (gradation: 46/33). The use of other combinations is not recommended.

Technical data:

Area of application: Road, Triathlon
Material: 3K carbon, aluminum 7075-T6, titanium GRD5
Technology: optimized for SRAM AXS Flattop
Bolt circle: 110 mm asymmetrical
Mounting: 4-arm spider asymmetric
Number of teeth: 33 teeth
Compatibility cranks: SRM Origin 9000, Shimano Dura Ace FC-9000 & Ultegra FC-6800
Chain compatibility: 12-speed SRAM eTap AXS Flattop
Mounting: internal
Chainline: depending on crank and frame
Offset: Standard
Adjustment options: -
Range (ovalization): -
Timing (force application): -
Color: black

Weight according to manufacturer: 33g
Weight self-weighed: 29g

Scope of delivery: 1x CARBON-TI chainring X-CarboRing X-AXS Carbon 4-Arm LK 110 asymmetrical | SRM Origin | 33 teeth inside

GTIN:

8056182348425

MPN:

XCR33I110SHAXS
