ZIPP Rear Hub ZR1 SL Center Lock | 12x142 mm Thru Axle | Shimano Road

Description
PDF (1)

ZIPP rear hub ZR1 SL Center Lock | 12x142 mm thru axle | Shimano Road

With the Zipp ZR1 SL, Zipp is launching a lightweight hub set with maximum performance. Based on the proven ZR1 hubs, the SL versions have a lighter hub shell and an optimized bearing system. Originally developed for the premium NSW wheels, the hubs are now also available separately.
The sophisticated freehub system offers 66 engagement points per wheel rotation and ensures quick engagement with six offset pawls organized in two groups of three pawls each. This means that three pawls always engage simultaneously, ensuring direct power transmission from the pedal to the wheel. Another clever detail: when the hub is dismantled, the pawls remain fixed, which makes maintenance much easier.
Equipped with high-quality ceramic hybrid ball bearings, the hubs have extremely low frictional resistance. For easy maintenance, the ZR1 SL hubs come with classic hub flanges for J-bend spokes, which are still the most common spoke shape today. The hubs can be installed on e-road bikes and e-gravel bikes with motors with a torque of up to 60 Nm.

Note: Contrary to the illustrations, the hub is supplied with a Shimano Road freehub body.

Technical data:

Area of application: Road bike, cyclocross, gravel, e-bike (motors with maximum 60 Nm)
Material: Aluminum, steel
Axle standard: 12x142 mm thru axle
Number of holes: 24 holes
Brake rotor mount: Center Lock
Freehub compatibility: Shimano 11-speed, 12-speed Road
Freehub type: 6 pawls, engaging in pairs / 66 engagement points per wheel rotation
Bearing: 4x ceramic hybrid bearings
Seal: double sealed
Spoke type: J-bend spokes
max. permissible spoke tension: n/a
maximum system weight: n/a
Color: black matt

Weight according to manufacturer: 222g
Weight when weighed: 218g (with SRAM XDR freehub body)

Scope of delivery: 1x ZIPP rear hub ZR1 SL Center Lock | 12x142 mm thru axle | Shimano Road

GTIN:

710845921254

MPN:

00.2018.055.002

Modell ID:

HU-ZR-1SL-A1

more  always opened

Service-Manual Zipp ZR1 SL Hubs

Manufacturer information

ZIPP

5315 Walt Pl

46254 Indianapolis

Indiana

Vereinigte Staaten

https://www.zipp.com/

Contact EU

Sram Europe Sales and Services B.V.

Paasbosweg 16

3862 ZS Nijkerk

Niederlande

https://www.sram.com/

SKU:	74828
Item weight:	218g

377,73 €

MSRP: 500,00 €

incl. 0% VAT , Plus

available from stock

available from stock

The item is in stock and will be delivered to you in about 2 - 6 business days (in the EU). When paying by cash in advance, we ship the order after receipt of payment. If your order contains products with different availabilities, this may delay the delivery.
more shipping info: Link »
