Description
THM CARBONES crank Clavicula SE Road LK 130 2-fold
The Clavicula SE is a full carbon crank with integrated carbon axle. During the development special emphasis was placed on an optimal structural design. To emphasize here is the Spider for the Kettenblattaufnahme. It was defined both geometrically and structurally only after analysis of the load paths. An extreme lateral stiffness for optimum shifting behavior and excellent circumferential rigidity for lossless power transmission has been created. Through this optimization, as a side effect, an above-average stiff and lightweight crankshaft system emerged.
THM-Carbones is particularly proud of a patent in the connection of the left crank with the axle . For the first time, a carbon-carbon material combination has been used here, which has been extensively and successfully tested in recent years. It is crucial that the relative movements between the teeth could be minimized here by identical fiber structure of external and internal teeth. As a result, there is practically no wear and no possibility of noise generation at this point. The Clavicula SE significantly shifts the standards set by THM-Carbones. It can be considered as a new reference in cranking.
Technical specifications:
Material: carbon, aluminum
Crank arm length: 170 / 172.5 / 175 mm
bolt circle diameter : 130 mm (5-hole)
Q-factor: 148 mm
chain line : 43.5 mm
Inner width: 118 mm max.
Rider weight: 120 kg
Finish: 3K matt or glossy
Weight: approx. 287g (crank without bottom bracket / chainrings)
Scope of delivery: 1x crank without bottom bracket!
operation manual
THM Clavicle SE | DE THM Clavicle SE | EN
The Clavicula SE is a full carbon crank with integrated carbon axle. During the development special emphasis was placed on an optimal structural design. To emphasize here is the Spider for the Kettenblattaufnahme. It was defined both geometrically and structurally only after analysis of the load paths. An extreme lateral stiffness for optimum shifting behavior and excellent circumferential rigidity for lossless power transmission has been created. Through this optimization, as a side effect, an above-average stiff and lightweight crankshaft system emerged.
THM-Carbones is particularly proud of a patent in the connection of the left crank with the axle . For the first time, a carbon-carbon material combination has been used here, which has been extensively and successfully tested in recent years. It is crucial that the relative movements between the teeth could be minimized here by identical fiber structure of external and internal teeth. As a result, there is practically no wear and no possibility of noise generation at this point. The Clavicula SE significantly shifts the standards set by THM-Carbones. It can be considered as a new reference in cranking.
Technical specifications:
Material: carbon, aluminum
Crank arm length: 170 / 172.5 / 175 mm
bolt circle diameter : 130 mm (5-hole)
Q-factor: 148 mm
chain line : 43.5 mm
Inner width: 118 mm max.
Rider weight: 120 kg
Finish: 3K matt or glossy
Weight: approx. 287g (crank without bottom bracket / chainrings)
Scope of delivery: 1x crank without bottom bracket!
operation manual
THM Clavicle SE | DE THM Clavicle SE | EN
available from stock
1.385,00 €
in about 3 - 4 months
1.385,00 €
