DT SWISS rim 29" EX 511
DT Swiss has stood for innovative products of the highest quality for years. Starting out as a manufacturer of high-quality spokes, the company has continuously expanded its product range. Since 2004, the Swiss have also had rims in their range, which they are constantly improving through feedback from cycling professionals and taking into account new developments in materials and manufacturing. Today, DT Swiss rims are among the most driven on the market.
Enduro may still be a young discipline, but at its core it is about the driver's inner desire to ride demanding terrain faster and faster. Actually, that's what mountain biking was all about from the start. And the EX 511 is exactly the right rim for this: It has the technology that has already delivered numerous EWS victories and packs it into a 30 mm wide profile. Then let's get started!
The rim is connected using the SBWT® welding process. The rim is stabilized with a block during welding and then CNC machined to guarantee a seamless transition. Convinced of the robustness, DT Swiss approves the rim up to a system weight of 130 kilograms. Like all DT Swiss rims in the current range, the EX 511 29" is also ideally suited for tubeless operation. All you need is a suitable tubeless tape, tubeless valves and sealing milk. The rim is supplied with suitable DT Squorx Pro Head® nipples and PHR washers The washers are mounted between the nipple and the rim to ensure an optimal fit of the nipple and thus protect the sensitive spoke ends.
We would be happy to make you an offer for a complete custom wheelset with hubs and spokes of your choice. Just send us an email to [email protected] !
Area of intended use : Tour, AllMountain, Trail, Enduro
Rim Type: Clincher (clincher and folding)
Brake type: only for disc brake
Internal width: 30mm
External width: 35mm
Rim Height: 21mm
Offset: 0 mm (symmetric)
Number of holes: 28 or 32 holes
tubeless capable: yes
recommended tire width: 47-89 mm
maximum tire pressure: 2.0-4.7 bar
Maximum system weight: 130 kg (rider, bike, clothing and possibly luggage)
maximum spoke tension: 1200N
Features: PHR washer, DT Pro Lock Squorx Head nipple
Valve hole bore: 6.5 mm (SV)
Weight: 570g (manufacturer information, without washers)
Weight weighed: 614g (28 holes)
Scope of delivery:
1x DT Swiss rim
including PHR washer and DT Pro Lock Squorx Pro Head nipple
