THM CARBONES bottom bracket MTB for Shimano Pressfit BB92 | BB89.5 frames
These bearing shells are suitable for mounting the THM Clavicula on frames with bottom bracket shells according to the Shimano Pressfit standard.
The standard is designed for the use of axles with a diameter of 30 mm. This axle diameter in combination with the large bearings extends the service life of the bearings, puts less stress on the axle and noticeably increases the stiffness of the crank.
Supplied with two aluminum compensation spacers.
Technical data:
Area of application: MTB
Bearing shell material: Steel
Bearing material: Steel ( THM Carbones)
Bottom bracket type: Shimano Pressfit BB92 | BB89.5 MTB
Bottom bracket shell width: 92 mm or 89.5 mm
Bottom bracket shell Ø: 41 mm
Crank shaft diameter: 30 mm
Crank compatibility: THM Clavicula M3 MTB, cranks with BB30 shaft
Tool holder: BB86/92 PressFit tool
Color: silver
Weight according to manufacturer: n.a.
Weight self-weighed: 80g
Scope of delivery: 1x THM Carbones bottom bracket MTB for Shimano Pressfit BB92 | BB89.5, incl. 2 compensation spacers
