SYNTACE Thru Axle X-12 | 135+ (142 mm) X-12

Description

SYNTACE thru axle X-12

With the X-12 thru axle system, Syntace is setting new standards.
Developed for all types of bikes, it offers the rider more rigidity, low weight and easy handling when removing and installing the rear wheel.
These properties come to light because the hub axle is guided into the dropouts using a threading aid and clamped in the rear triangle under high axial tension.
The thru axle fits into hubs that are designed with their axle diameter for X-12 axle n (corresponding hubs are available in our shop , e.g. from Extralite, Tune and American Classic).

Note: The thru axle only fits frames with appropriate dropouts. The actual installation widths are 135+7 mm (X-12), 150+7 mm (3.5 mm wide end caps per side) and 142+ 6 mm (3 mm per side) Boost rear ends.

Syntace offers a 10-year guarantee on all of its items if they are installed and used according to the assembly instructions.

Technical data:

Material: aluminum
Axle length: 159 mm | 174 mm | 165 mm
Installation width: 142 mm (135+ mm) | 157mm (150+mm) | 148mm Boost
Thread: M12 x 1.0
Color: Black

Weight according to manufacturer: 40g (135+), 44g (150+)
Weight weighed: 41g

Scope of delivery: SYNTACE thru axle X-12

Note: Please note the information under the following link
