R2BIKE wheelset e-bike 29" EN DH | Hope 6-hole hubs | Newmen aluminum rims
Application: E-bike, Enduro EN, Downhill DH
This wheelset can withstand the special stresses of an e-bike drive. The indestructible Tune hubs and the superbly crafted Newmen rims are forgiving of the occasional riding error. The well-balanced selection of components guarantees you a high level of reliability and a long service life.
Hubs
The Pro 5 e-bike hubs from the English cult manufacturer from Barnoldswick are at the center. The experience gained from 30 years of designing and manufacturing high-quality drive elements has been incorporated into their development with the aim of improving proven technology in order to meet the demands of current and future bicycle technology.
The design of the rear hub differs significantly from its predecessor, with an enlarged body that generates more rigidity without increasing the weight. This is noticeable above all in a much more direct ride. At the same time, the diameter of the spoke flange has been increased, making it easier to build very stable wheels.
The highlight of the rear wheel hub is the new freewheel system with 6 pawls. All six are engaged simultaneously when riding and can absorb and distribute the high power of the e-bike drive evenly. In addition, the freehub gearing has been increased from 44 (Pro 4) to 54 teeth, resulting in a low freewheel travel of just 6.66°.
The hub can withstand negative external influences for a long time, thanks to the high-quality anodization and the very well-sealed stainless steel industrial bearings. Should the ravages of time take their toll on the hub, it can be dismantled and serviced with little effort. It can also be easily converted to a different hub standard.
Rims
Newmen offers a special rim for every application within the Beskar series. Whether cross-country, all-mountain or downhill, you will always get a model that is uncompromisingly customized, but they all have one thing in common: Newmen's high quality.
With the Beskars 30 on your bike, you will be the absolute king on every adventure. They shine with low weight and first-class riding characteristics. The perfectly crafted aluminium is impact-resistant anodized and, together with the slightly angular cross-section, gives the rims incredible stability. This enables precise steering movements at all times. The rim joint has been elaborately welded and ground and guarantees a long service life. The very generous inner width of 30 mm gives the tire an optimally rounded shape, which is reflected in better grip and more comfort. The latter is also promoted by the very flat profile. Newmen has opted for a rim flange with hooks. This means that the tire sits securely at all times, even in difficult passages or with low air pressure, and the risk of it coming off is significantly minimized. Depending on the area of use, it is also reinforced and can easily withstand punctures.
Newmen also recommends the use of MG washer washers for the Beskar. These ensure very high "Spoke-Pull-Out" values on the rim base, despite the low wall thickness there, and thus bring additional rigidity to the wheel.
Spokes
The Race spoke is the classic from Sapim! It is a round spoke with a butted center section with a diameter of 1.8 mm. This provides more damping than non-tapered spokes. In addition, short load peaks can be better digested. The Race spoke enables very stiff and stable wheels for practically any application. The weight including nipple is approx. 6.95g per piece.
Wheel construction at R2-Bike
Our wheels are assembled completely by hand by our wheel builders. During the entire assembly process, great importance is attached to ensuring that not only the concentricity is correct, but also that the spoke tension is as even as possible. This special care allows us to give the first owner a lifetime guarantee against spoke breakage, as long as it was not caused by force.
The following services are also included for first-time buyers:
You get a universal wheel bag for all common sizes included.
You will receive a spare spoke with nipple in all required spoke lengths so that you can repair the wheel quickly after an accident.
Within 2 years of purchase, you will receive a free initial inspection of the wheel, during which the resulting work is completely free of charge. Only shipping costs are incurred.
You get a crash replacement promise: If your wheel is damaged within 2 years of purchase due to force majeure, we will rebuild it once. We grant a 100% discount on all labor costs and only charge for the material.
Technical data:
Area of application: E-bike, Enduro EN, Downhill DH
Wheel size: 29" (ETRTO: 622 x 30)
Rim type: clincher (clincher and folding tires)
Brake type: Disc brake
Brake disk mount: 6-hole
Weights:
2280g (lightest version: Boost + Boost, Strong + Strong, Sapim Race)
2483g (heaviest version: Boost + Boost, Strong + DH, Sapim Race)
Notes:
Deviations in weight are possible due to manufacturing variations in all components. The specifications are generally calculated without rim tape, valves and decals/rim stickers.
The specified delivery time refers to the usual time required to assemble the wheelset and does not reflect the availability of the individual parts.
If you require a special spoking on the rear wheel, e.g. for the Cannondale Ai rear triangle or for EVO6, please contact our service team.
Scope of delivery:
1x complete wheelset, fully assembled (hubs, rims, spokes and nipples)
1x wheel bag
4x spare spokes including nipples
1x assembly certificate
2x hologram stickers
