Description
PRO Discover Carbon 20 degree handlebar
The PRO Discover Carbon handlebar offers comfort, control and efficiency for long days in the saddle, whether you're on the road, descending the gravel or conquering a big mountain. Its compact Ergo bar shape prevents fatigue and allows easy gripping of any hand size. The large outer bend (flare) of 20 degrees ensures a stable and secure grip on any terrain. The upper handlebar offers clamping space for additional brake levers (e.g. Shimano GRX). For a tidy cockpit, the option for internal cable routing when using Shimano Di2 shifters.
Technical specifications:
Application area: Gravel
Material: carbon
Handlebar clamp Ø: 31.8 mm
Handlebar width top bar (centre - centre): 400 mm, 420 mm or 440 mm
Handlebar width lower link (outer - outer): 500 mm, 520 mm or 540 mm
Lower link diameter: 24 mm
Advance / Reach: 75 mm
Lowering / Drop: 105 mm
Outer bend / Flare: 20
Inner bend: n.a.
Backsweep: 0
max. rider weight (rider, clothing and luggage): n.a.
max. permissible torque: stem 4 Nm | components 4 Nm
Optics/Finish: matt
Weight according to manufacturer: 205g
Weight weighed: 210g (440 mm)
Scope of delivery: 1x PRO Discover Carbon handlebar 20 degrees
