ABSOLUTE BLACK chainring Premium Sub Compact oval 2-fold LK 110/5 hole | 48 teeth black outside
With the Premium Sub Compact chainrings from Absolute Black you can conquer any angle with your racing bike or gravel bike! The symmetrical 110 millimeter bolt circle diameter is suitable for all common Shimano Road cranks with 5-arm mounting. The translation variant with 48-32 teeth helps to maintain a smooth step even on the steepest ramps.
The chainrings are CNC-machined from one piece of aluminum, creating the perfect combination of low weight and excellent durability for your bike. Elaborately milled switching ramps ensure excellent switching performance. The Sub-Compact chainrings are coordinated in such a way that only a combination of 48-32 teeth is possible. Thanks to the milling of a 5 millimeter thick aluminum plate, the Absolute Black chainrings are among the stiffest on the market. The large cutouts keep the weight low and make the chainrings an eye-catcher. The oval shape smooths the force peaks during the crank rotation. As a result, you have a more even step, especially on the mountain, and the muscles tire less. The lower force peaks also reduce the stress on the knees.
NOTE: The matching special screws for fastening are included in the scope of delivery of the matching small chainring.
Technical specifications:
intended use : Gravel, CX, Road
Material: 7075 Txxx aluminum, type II anodised
Technology: aB super compact
bolt circle diameter : 110 mm
Attachment: 5-arm spider
Number of teeth: 48 teeth
Compatibility cranks : Shimano Dura-Ace 7950, Ultegra 6750, Shimano 105- 5750, Tiagra 4650, FSA, Praxis Alba & Zayante
S-Works, SRAM NHB (non-hidden-bolt) cranks such as Red22 Force22, Rival22, Apex22
NO compatibility with SRAM YAW front derailleurs!
Compatibility chain: 10, 11, 12-speed
Mounting position: outside
chain line : depending on the crank used
Offset: -2.5 mm (towards the frame)
Adjustment options: none
Range (ovalization): 10.9%
Timing (force application): 108 ° - 110.5 ° crank position after top dead center (TDC)
Color: Black
Weight according to the manufacturer: 115g
Weight weighed: 119g
Scope of delivery: 1x ABSOLUTE BLACK chainring Premium Sub Compact oval 2-fold LK 110/5 hole | 48 teeth black outside
