YUNIPER seat clamp Ultralight Extended | black
The reinforced version of the legendary Yuniper Ultralight seat clamp. With a weight of only 8 grams, the clamp milled from 7075 T6 aluminum is still one of the absolute lightweights. In contrast to the Ultralight version, the Extended has a ring that is supported on the top of the seat tube and more material thickness on the top and bottom of the clamping ring. The saddle height is adjusted using a lightweight M5x10 hexagon socket screw made of titanium.
Technical data:
Clamp material: Aluminum 7075-T6
Screw material: Titanium
Seat tube Ø: 30 mm; 31.8 mm or 34.9 mm
Height: 12 mm (0.5 mm rim)
Clamp height: 11.5 mm
Max. permissible torque: 4 Nm
Tool holder: 4 mm hexagon socket
Color: black
Weight according to manufacturer: approx. 9g
Weight self-weighed: 8.1g (30 mm); 8.4g ( 31.8 mm); 8.9g (34.9 mm)
Scope of delivery: 1 YUNIPER seat clamp Ultralight Extended | black incl. titanium bolt
