Wheelset 29" XC | NONPLUS Components 6-Hole Hubs | Race Face Aluminum Rims

Item number:
50985
Product weight: 1460 g
Brands: r2-bike

from 1.047,50 €
MSRP: 1.171,48 €
You save 10,58%, that is 123,98 €

including 19% VAT. , free shipping (DE) / shipping time info (Sperrgut)

Availability:
handmade - in about 2 - 3 months
Configure now

We can't deliver this item to your chosen country.


NONPLUS Components Front Hub J-Bend 6-Hole
NONPLUS Components Front Hub J-Bend 6-Hole
  • Brake disc mount: 6-hole
    Spoke type: J-Bend (curved)
    Storage: 2x industrial deep groove ball bearings
    Color: Black
    Weight: 86g

    With the 110 millimeter wide BOOST hub, stiffer wheels with a more even spoke angle can be built on both sides thanks to a wider flange spacing.

NONPLUS Components Rear Hub J-Bend 6-Hole
NONPLUS Components Rear Hub J-Bend 6-Hole
  • Brake disc mount: 6-hole
    Spoke type: J-Bend (curved)
    Storage: 4x industrial ball bearings
    Freewheel type: bevel gearing with 45 detents
    Freewheel compatibility: 12-speed Shimano Micro Spline
    Color: Black
    Weight: 187g

    With the 157 millimeter wide SuperBOOST hub, stiffer wheels can be built with a more even spoke angle on both sides thanks to a wider flange distance. In addition, the wider rear end allows the use of bulky tires.

Race Face Rims Cross Country
Race Face Rims Cross Country
  • Intended use: Cross Country XC
    ETRTO: 622x25
    Inside width: 25 mm
    Outer width: 28.1 mm
    Rim height: 20 mm
    Offset: 3.0 mm (asymmetrical)
    recommended tire width: 48 - 68 mm
    maximum tire pressure: N / A
    maximum system weight: n / a
    Color / finish: black / anodized
    Weight: 450g
Spokes
Spokes
  • Application: Road, Gravel, Cross Country, Trail
    Weight incl. nipple: approx. 5.45g (1 piece)

    The wing spoke made of cold drawn Sweden steel has an elliptical shape which takes advantage of the flat, light and aerodynamically more favorable but weak aero spoke and the stronger but less aerodynamic and heavy classic round spoke. This gives it the diameter necessary for torque transmission and at the same time favorable and superior aerodynamic properties with low weight!


Colour Spoke Nipples
Colour Spoke Nipples
  • The nipples are made of brass in order to achieve the best possible and long-lasting result in terms of color. The robust material is insensitive to corrosion and does not stick to the thread of your spokes, so that re-centering is still possible without any problems even after years of use. In addition, they are neither attacked nor damaged by any sealing milk that may have got into the rim well.

    Weight per piece: 1.0g

Rim Tape | Tubeless Kit
Rim Tape | Tubeless Kit
Your configuration
Product details

Description

Wheelset 29 "XC | NONPLUS Components 6-hole hubs | Race Face aluminum rims

intended use : Cross Country XC

With this wheelset, even racers can really let it go. The light and stable NONPLUS Components hubs as well as the stable Race Face rims forgive driving mistakes. The balanced selection of components guarantees you a high level of reliability and a long service life.

Hubs
The small forge from Murr in Baden-Württemberg has been manufacturing lightweight yet stable bicycle hubs since 2018. New concepts are constantly being developed and patents registered so that new standards can also be set in the future.
A hub body, made of high-quality, hard-anodized aluminum, rotates around the elaborately sealed industrial deep groove ball bearings. This has a special ventilation system, which prevents the creation of negative pressure due to temperature fluctuations in the hub. As a result, no water is sucked through the ball bearings, which ensures a significantly longer service life and noticeably easier running of the bearings.
Thanks to high-precision manufacturing and perfect quality control, the hubs of the second generation manage without the previously used adjuster for the bearing play. This means that you always have a perfectly adjusted hub with a smooth, easy run.
The unique freewheel mechanism with bevel teeth of the NONPLUS hubs has approx. 400% more contact surface than conventional systems and enables maximum power transmission with minimal wear. The forces are transmitted over a large area instead of selectively. The 45 defined rest points immediately convert your start into propulsion without much idle travel.

rims
The ARC rim is now one of the favorite rims of wheel builders from all over the world. With the new offset variants, even stiffer and more durable wheels can be built. This is achieved through a more balanced spoke tension between the drive side and the non-drive side.
A specially shaped rim well with a central recess and minimalist, short hooks on the rim flange hold the tire securely on the rim in every situation, even with low air pressures. The grip is also significantly improved due to the larger contact surface of the tire.
The rim is made of forged aluminum 6069, the joint is inserted and additionally glued to increase durability and reduce weight. The black anodized finish saves weight and gives the rims a subtle look with their vinyl decals. Of course, the rims can be converted for tubeless use.


Wheel construction at R2-Bike

Our wheels are completely assembled by hand by our wheel builders. During the entire construction process, it is important that not only the concentricity is correct, but also that the spoke tension is as even as possible. The special care allows us to give a lifelong guarantee against broken spokes, as long as this was not caused by force!

You will also receive the following services for our balance bikes:

A universal impeller bag for all common sizes.
A spare spoke + nipple in all required spoke lengths so that the wheel can be repaired at short notice even after an accident.
A free initial inspection of the impeller, during which the resulting work is completely free! Only shipping costs are charged.
A crash replacement promise. If your wheel is damaged due to force majeure, we will rebuild your wheel once. We grant a 100% discount on all labor costs and only charge the material!


Technical specifications:

intended use : Cross Country XC
Impeller size: 29 "(ETRTO: 622 x 25)
Rim type: Clincher (wire and folding tires)
Brake type: disc brake
Brake disc mount: 6-hole

Weights:

1460g (lightest variant: Boost + Boost, Race Face 25, Sapim CX-Ray)
1561g (heaviest variant: Boost + SuperBoost, Race Face 25, Sapim Race)

Note:
Due to manufacturing fluctuations for all components, deviations in weight are possible. The information is usually determined without rim tape, valves and decals / rim stickers.

The specified delivery time refers to the usual duration for the assembly of the wheelset and does not reflect the availability of the individual parts.

If you would like a special spoke on the rear wheel, e.g. for the Cannondale Ai rear triangle or for EVO6, please contact our service team.


Scope of delivery:

1x complete wheelset, fully assembled (hubs, rims, spokes and nipples)
1x wheel bag
4x spare spokes including nipples
1x construction certificate
2x hologram sticker
