Description
Wheelset 29" XC | DT Swiss 350 MTB 6-hole hubs | Newmen aluminum rims
intended use : Cross Country XC to Trail TR
Stable, functional and also inexpensive - this is the best way to characterize this wheelset. The combination of Newmen aluminum rims and the proven DT-Swiss hubs should therefore always be on the short list. The balanced selection of components guarantees you high reliability and a long service life.
hubs
Switzerland is known for good chocolate, first-class cheese and wonders of precision engineering. The dedication to detail that produces these products is also reflected in the DT Swiss 350 hubs. Above all, the love for mechanics is easy to identify. Due to their simple but well thought-out construction, the current 350 hubs have become significantly lighter compared to the previous versions. The ratchet freewheel system, tried and tested by the DT-Swiss 240 hubs, makes the hubs an extremely reliable companion. Compared to pawl systems, the built-in toothed disk freewheel offers a more extensive power transmission, which significantly reduces wear. With 36 teeth, the hub reacts very directly to acceleration. The new shape of the end caps makes dismantling even easier, so that changing over to other axle type standards is even easier.
rims
This high-end aluminum rim was developed for riders who want to throw themselves into cross-country races with light but stable wheels and want to compete for victory. Like all Newmen Evolution SL components, the rim consists of a high-strength aluminum alloy and impresses with first-class mechanical properties and low weight.
The flared and reinforced rim flanges are more resistant to damage from punctures and give the tire a rounder shape and thus even better cornering.
The rim profile with the straight nipple contact surface is specially designed for the use of specially developed washers (MG washer) and ensures very high "spoke pull out" values with very low wall thickness in this area.
Impeller construction at R2-Bike
Our wheels are assembled entirely by hand by our wheel builders. During the entire construction, it is important that not only the concentricity is right, but also that the spoke tension is as even as possible. The special care allows us to give a lifetime guarantee against broken spokes, as long as this is not caused by violence!
You will also receive the following services with our wheels:
A universal impeller bag for all common sizes.
A spare spoke + nipple in all required spoke lengths to be able to repair the impeller at short notice even after an accident.
A free initial check of the impeller, where the resulting work is completely free! Only shipping costs are charged.
A crash replacement promise. If your wheel is damaged due to force majeure, we will rebuild your wheel once. We grant a 100% discount on all labor costs and only charge for the material!
Technical specifications:
intended use : Cross Country XC to Trail TR
Wheel size: 29" (ETRTO: 622 x 25 or 30 mm)
Rim Type: Clincher (clincher and folding)
Brake type: disc brake
Brake disc mount: 6-hole
weights:
1527g (lightest variant: 15x100 mm + 12x142 mm, SRAM XD, SL XA 25 rims, Sapim CX-Ray)
1899g (heaviest variant: Boost + Boost, Shimano/SRAM, SL A. 30 rims, Sapim Race)
Notice:
Due to manufacturing variations in all components, deviations in weight are possible. The information is usually determined without rim tape, valves and decals/rim stickers.
The specified delivery time refers to the usual time it takes to build the wheelset and does not reflect the availability of the individual parts.
Scope of delivery:
1x complete wheelset, fully assembled (hubs, rims, spokes and nipples)
1x wheel bag
4x spare spokes including nipples
1x assembly certificate
2x hologram stickers
