WOLFTOOTH Chainring Direct Mount BOOST Drop-Stop for Race Face Cinch Crank
This good piece is chainring and spider in one and can be mounted on any Race Face crank with cinch attachment system. These are, for example, the NEXT SL carbon crank or the aluminum crank turbine. A direct mount chainring offers a clean look and a higher stiffness with low weight. Wolftooth's drop-stop technology eliminates the need for a chain guide when using a 1x9, 1x10 or 1x11 drive. This is made possible by special teeth, which are narrow and wide in turn. For a reliable guidance of the chain we recommend the use of a derailleur with increased cage tension. Shimano offers these under the name Shadow +. Sram calls it Type2 or Type2.1. For maximum strength and low wear, the chainring is CNC machined from one piece of 7075 aluminum and then anodized.
Technical specifications:
intended use : MTB
Material: aluminum 7075
Technology: Narrow Wide
bolt circle diameter : ---
Attachment: Direct Mount
Number of teeth: 26, 28, 30, 32 or 34 teeth
Compatibility cranks : Race Face Cinch cranks
Compatibility Chain: 9x, 10-speed , 11-speed or 12-speed (SRAM Eagle)
Mounting position: outside
chain line : 52 mm | BOOST
Offset: 3 mm
Adjustment options: none
Range (ovalization): ---
Timing (force introduction): ---
Color: Black
Weight according to manufacturer: 26t - 48g, 28t - 54g, 30t - 58g, 32t - 63g, 34t - 69g, 36t - 75g
Weight weighed: 28t - 54g, 30t - 59g, 32t - 62g
Scope of supply : 1x WOLFTOOTH chainring Direct Mount BOOST Drop-Stop for Race Face Cinch Crank
