SUPERNOVA E-Bike Headlight M99 Mini Pure E-25 U-Series | StVZO
Finally being treated with more respect on the road! As an e-bike rider, your speed is often underestimated due to your relaxed pedaling style. So that this doesn't happen to you again in the future, this compact headlight now offers the solution: With 450 lumens and 150 lux, the extraordinarily wide and homogeneous low beam guarantees the best possible safety at any speed. The unprecedented width of the light carpet ensures ideal visibility even when cornering. Of course StVZO approved.
M99 Matrix Mirror
Matching the 99 individually calculated mirror surfaces to the intelligent LED matrix was a complex development project. Only through the use of up to 9 intelligently controllable automotive LEDs in combination with multiple computer calculations of the concave and convex catoptric facets of the mirror was it possible to create this future-oriented product.
Calculated ice cold
In order for the high-power LEDs to work efficiently, they need optimal cooling. This is where Supernova's many years of experience come into play. Through careful material selection and thermal simulation, the housing and electronics have been designed in such a way that the LEDs can reach their maximum output at all times.
Technical specifications:
Material: Aluminum CNC milled
Dimensions (L x W x H): 37 x 78 x 50 mm (without cable)
Supply voltage: 5 - 13.5 V DC
Power supply: 1450 mm Supernova connection cable
Compatibility: e-bikes up to 25km/h
Illuminant: LED
Optics: M99 Matrix Mirror
Functions: low beam 450 lumens, 150 lux (5.2W)
Protection class: not specified
Approval StVZO: K license plate, for e-bikes up to 25km/h
Colour: matte black
Weight according to the manufacturer: 110g (without cable)
Weight weighed: 122g (without cable)
Scope of delivery:
1x SUPERNOVA e-bike headlight M99 Mini Pure E-25 U series | StVZO
1x 1450mm connection cable
