Description
Shimano XT derailleurs FD-M8020-D Side Swing | 2 times | High Direct Mount
Shimano's new FD-M8020 derailleur for 2-fold cranksets which offers a groundbreaking design with a completely new approach. Specifically designed with modern trail bikes, the Shimano XT Side-swing front derailleur 15 mm provides more tire clearance, while the completely redesigned cable routing reduces the operating forces when shifting dramatically. Shimano XT derailleur M8020 is specifically designed for larger wheels and suspension travel and provides a whole new level with derailleurs.
- Superlight shifts
- New construction with versatile mounting options and new cable routing
- Excellent and easy adjustability
- To 15 mm increased tire clearance enables shorter chainstays
- Designed in terms of trail bike with long suspension.
- Compatible with Shimano cranks Outboard (when using appropriate framework)
Technical specifications:
Finish: Side Swing, fixing on High Direct Mount socket on the seat tube
Compatibility Gear: 2 / 3x11-speed Shimano Dyna-SYS11
Compatibility Chain: Shimano HG-X11
Compatibility crank: standard crank, crank Outboard (only when using appropriate framework)
chain line: 48.8 mm
Recommendation chainring: 34-38 teeth
Capacity: 2-fold with 10 teeth difference between the largest and smallest leaf
Color: black - silver
Weight: about 136g
Shimano's new FD-M8020 derailleur for 2-fold cranksets which offers a groundbreaking design with a completely new approach. Specifically designed with modern trail bikes, the Shimano XT Side-swing front derailleur 15 mm provides more tire clearance, while the completely redesigned cable routing reduces the operating forces when shifting dramatically. Shimano XT derailleur M8020 is specifically designed for larger wheels and suspension travel and provides a whole new level with derailleurs.
- Superlight shifts
- New construction with versatile mounting options and new cable routing
- Excellent and easy adjustability
- To 15 mm increased tire clearance enables shorter chainstays
- Designed in terms of trail bike with long suspension.
- Compatible with Shimano cranks Outboard (when using appropriate framework)
Technical specifications:
Finish: Side Swing, fixing on High Direct Mount socket on the seat tube
Compatibility Gear: 2 / 3x11-speed Shimano Dyna-SYS11
Compatibility Chain: Shimano HG-X11
Compatibility crank: standard crank, crank Outboard (only when using appropriate framework)
chain line: 48.8 mm
Recommendation chainring: 34-38 teeth
Capacity: 2-fold with 10 teeth difference between the largest and smallest leaf
Color: black - silver
Weight: about 136g
EAN:
4524667920724
MPN:
IFDM8020D6
