RITCHEY Seatpost Superlogic One Bolt Carbon 31.6 mm
The Superlogic 1-bolt seatpost is one of the lightest and most rugged seat post constructions in the world. A patented SideBinder clamp design uses a single 5mm screw for quick and safe adjustment, while the low head provides optimum saddle spacing. The Superlogic 1-bolt seatpost features a precision-forged aluminum clamp and a wide saddle clamp reduces stress on lightweight seatposts.
Note: Replaceable clamps provide compatibility for all common rail sizes.
Technical specifications:
intended use : Road bike, MTB
Material: Carbon UD
Material screws: steel
Diameter: 31.6 mm
Available sizes: 300, 350 and 400 mm
Offset: 25 mm
Minimum insertion depth: 70 mm
minute possible usable height: 90 mm (300 mm), 150 mm (350 mm), 190 mm (400 mm)
Max. possible usable height: 190 mm (300 mm), 250 mm (350 mm), 290 mm (400 mm) (upper edge of saddle clamp to lower edge of saddle frame)
Compatibility seat stays: 7x7 mm (exchangeable clamp article no .: 4025)
Driver's weight: 110 kg (driver, clothes and possibly luggage)
Finish: UD-Carbon, matt
Color / logos: black / gray-matt
Weight according to manufacturer: n / a
Weight weighed: 168g (350mm)
Scope of supply: 1x RITCHEY seatpost Superlogic One Bolt Carbon 31.6 mm
The Superlogic 1-bolt seatpost is one of the lightest and most rugged seat post constructions in the world. A patented SideBinder clamp design uses a single 5mm screw for quick and safe adjustment, while the low head provides optimum saddle spacing. The Superlogic 1-bolt seatpost features a precision-forged aluminum clamp and a wide saddle clamp reduces stress on lightweight seatposts.
Note: Replaceable clamps provide compatibility for all common rail sizes.
Technical specifications:
intended use : Road bike, MTB
Material: Carbon UD
Material screws: steel
Diameter: 31.6 mm
Available sizes: 300, 350 and 400 mm
Offset: 25 mm
Minimum insertion depth: 70 mm
minute possible usable height: 90 mm (300 mm), 150 mm (350 mm), 190 mm (400 mm)
Max. possible usable height: 190 mm (300 mm), 250 mm (350 mm), 290 mm (400 mm) (upper edge of saddle clamp to lower edge of saddle frame)
Compatibility seat stays: 7x7 mm (exchangeable clamp article no .: 4025)
Driver's weight: 110 kg (driver, clothes and possibly luggage)
Finish: UD-Carbon, matt
Color / logos: black / gray-matt
Weight according to manufacturer: n / a
Weight weighed: 168g (350mm)
Scope of supply: 1x RITCHEY seatpost Superlogic One Bolt Carbon 31.6 mm
MPN:
41066117007
