RITCHEY headset Comp V2 1 1/8 "| EC34 / 28.6 | EC34 / 30
The 1 1/8 "threaded Ritchey Comp Cartridge Logic headset has a cartridge chamber and a smaller top bearing to save weight, while the lightweight aluminum cups are deep for solid insertion.
A sealed design promises minimal intrusion of the elements.
Type: Ahead, EC (External Cup)
Steerer: 1 1/8 "
SHIS upper part: EC34 / 28.6
SHIS lower part: EC34 / 30
Press-in dimension above Ø: 34 mm
Press-in dimension below Ø: 34 mm
Outside diameter at the top: 46.76 mm
Outside diameter below: 47.75 mm
Construction height above: 18.5 mm
Height below: 23.4 mm
bearing : sealed 45/45 degree half cartridge
Weight according to the manufacturer: n / a
Weight weighed: 135g (headset including claw, ahead cap and screw)
Scope of delivery:
1x RITCHEY headset Comp V2 1 1/8 "| EC34 / 28.6 | EC34 / 30
1x ahead cap including screw
1x Ahead claw
