Description
NEWMEN rear wheel 29 "Evolution SL XA25 aluminum FADE 6-hole | 12x148 mm thru-axle BOOST
This rear wheel offers you pure cross country fun. The 25 mm inner width of the rim saves weight, but still allows the installation of tires up to 2.4 "wide. It allows lower air pressure and makes your bike safer, more comfortable and more playful.
Due to the special rim profile, with the completely edge-free outer contour, this rim is very light and at the same time resistant to external forces. The exposed rim flanks are more resistant to dents than conventional straight rim flanks and give the tire a rounder shape and thus more cornering grip.
With the FADE hubs, Newmen has placed user-friendliness in the foreground. It is not necessary to adjust the axial bearing play. The bearings are precisely and stress-free ex works. In connection with the Sapim D-light spokes you are prepared for anything and can spend the time saved longer on your favorite trail.
In addition, a pawl freewheel now converts your acceleration into propulsion. The advantage is a low level of noise when rolling. To ensure reliable operation, the pawls were made very short and wide in order to better distribute the forces that occur.
Despite the relatively low weight of the hubs, safety was not compromised. It is better to build in a little more material at critical points, like. For example, at the transition between the brake disc and spoke mounts, as risking a defect.
All Newmen products are developed and produced in Germany. This means that the manufacturing process can be optimized at any time and consistently high quality guaranteed.
Technical specifications:
intended use : Cross Country
Impeller size: 29 "(ETRTO: 622 x 25 mm)
Rim type: Clincher (wire and folding tires)
Brake type: only for disc brake
Brake disc mount: 6-hole (IS2000)
Material: aluminum
Inner width: 25 mm
External width: n / a
Rim height: 17.5 mm
Number of holes: 28 holes
axle type : 12x148 mm thru-axle BOOST
bearing : 4x industrial deep groove ball bearings
Freewheel compatibility: 9, 10, 11-speed MTB Shimano | SRAM, 11-, 12-speed SRAM XD or 12-speed Shimano Micro Spline
Freewheel type: pawl freewheel with 3 pawls and 36 notches
Spokes: Sapim D-Light / Straightpull (black)
tubeless capable: yes
Recommended tire width: 50 - 61 mm
Maximum rider weight: 125 kg (rider, bike, clothing and possibly luggage)
Finish: anodized matt
Color: black rim with white and gray logos, hub: black
Weight according to the manufacturer: 785g
Weight weighed: 837g (SRAM XD), 853.7g (Shimano Microspline)
Scope of delivery: 1x NEWMEN rear wheel 29 "Evolution SL XA25 aluminum FADE 6-hole | 12x148 mm thru-axle BOOST
