METI Titan Shimano XTR Pedals PD-M9100 SPD Race | Titanium axis short -3 mm
The Shimano XTR pedals have always been known in the racing scene for their very good durability and function. Compared to its predecessor, the footprint of the 9100 pedal has been increased by a wider, flattened pedal body. Therefore, the M9100 pedals offer improved power transmission and more control in technically demanding passages. The shape of the pedals has been optimized for adverse weather conditions. Thanks to the better self-cleaning achieved, clicking in and out does not cause any problems even on muddy track conditions.
However, the perfect function was always offset by a few grams too much. Thanks to the Meti titanium axles, this is now an end. The optimized axle are manufactured by Meti in Italy from high-strength grade 5 titanium on modern CNC machines.
While the outer bearing of two Ceramic hybrid ball bearings maintenance-free is adopted, the original plain bearings is on the inside further used. In addition to the weight saved, this construction also results in a silky smooth run. axle n are approved for a driver's weight including clothing, backpack, etc. up to 100kg.
The result of the diet is quite impressive. The pedals have lost a little more than 60g in weight and now only weigh 258g per pair without having to sacrifice a touch of their perfect function. This is what sensible tuning looks like.
intended use : XC, Marathon, CX, Gravel
Pedal axle material: Grade 5 titanium
Pedal body material: aluminum
bearing : 2x sealed industrial bearings (Ceramic Hybrid) / 1x slide bearing
Freedom of movement: +/- 5 ° of the heel
Release hardness: adjustable
Q factor: 52 mm
Compatibility sole: Shimano SPD
Compatibility pedal plate: Shimano SPD (MTB)
Weight limit: 100 kg (driver, clothing and possibly luggage)
Colors: gray / silver
Weight according to the manufacturer:
Weight weighed: 257g per pair, excluding cleats
Scope of delivery: 1 pair of METI titanium Shimano XTR pedals PD-M9100 SPD Race | Titanium axle short -3 mm incl.cleats (SM-SH51)
