Description
MCFK wheelset 29" MTB carbon 35 mm | DT Swiss 240s EXP Straightpull 6-hole hubs | Decals black
With this wheelset you can really let it rip in any terrain. The indestructible DT Swiss 240s hubs and the excellently processed MCFK rims also forgive a driving mistake. The balanced selection of components guarantees you high reliability and a long service life.
Hubs DT Swiss 240 EXP
Lighter, stiffer, more precise and easier to maintain - these are the strengths of the newly launched DT Swiss 240 hubs. These properties were achieved through the Ratchet EXP technology. With this, the hubs not only get by with fewer components and thus lower weight and less wear, it also allows the bearing on the drive side to be placed significantly further out. The larger distance between the bearings results in a higher rigidity of the hub, a lower bearing load and thus greater durability. The stiffness on the hub body serves to distribute the load more evenly on the spokes. Driving and braking forces are transmitted even better from both spoke flanges to all spokes. One-sided load peaks are prevented, which protects the hub, spokes and rim. With its large contact surface and 36 locking points, the tried-and-tested toothed disc freewheel system ensures extremely direct and reliable power transmission.
Rims MCFK carbon 35 mm
These light, stable and beautifully finished carbon rims come from the lightweight construction specialists from Leipzig. The hookless construction not only makes it easier to mount the tires, it also ensures a more stable rim flange, since the carbon fibers can be placed consistently. Laminated spoke holes instead of conventionally drilled ones provide extra stability and durability. The asymmetrical structure of the rims enables more even spoke tension, which further increases the rigidity of a complete wheel. With an enormous inner width, these rims offer enough space even for wide tires. The best prerequisites for a plus in comfort and optimum traction.
Spokes Sapim CX-Ray
With the CX-Ray, Sapim has succeeded in developing an extraordinary spoke. In addition to its low weight, it has exceptional resilience and flexibility. This also results in the large area of intended use . It doesn't matter whether you are a racing cyclist or a mountain biker, everyone benefits from these positive characteristics. In addition, the flattened center section ensures excellent aerodynamics. The high material quality enables the construction of stable wheels and guarantees a long service life.
Sapim's CX-Ray spokes can be installed in all standard hub holes.
Technical specifications:
Area of intended use : trail, all-mountain, enduro
Wheel size: 29" (ETRTO 35-622)
Rim Type: Clincher (clincher and folding)
Brake type: disc brake
Brake pads: -
Material rims: UD carbon
Inner width: 35 mm (manufacturer information), 36 mm (self-measured)
External width: 44mm
Rim Height: 29mm
Number of holes: front 28 / rear 28
Spokes: Sapim CX-Ray 2.0 | 0.9 - 2.2 | 2.0, black
Lacing pattern: 3-crossed at the front | crossed 3 times at the back
Axle standard front: axle type mm Boost
Rear axle type standard: 12x148 mm Boost
Brake disc mount: 6-hole
bearing front: 2x industrial bearings
Bearing rear: 4x industrial bearing
Freewheel compatibility: 11, 12-speed SRAM XD or 12-speed Shimano Micro Spline
Freehub Type: Ratchet EXP, 2 ratchet, 36 detents
recommended tire width: 2.1" - 2.7" (55-70 mm)
max. air pressure: 5 bar
maximum system weight: 125 kg (rider, bike, clothing and possibly luggage)
tubeless capable: yes
Valve hole: Presta valve (SV)
Color rim / finish: black / UD carbon matt
Color decor: black
Color hubs: black with white and red lettering
Weight according to the manufacturer: 1330g (wheelset)
Weight weighed:
Scope of delivery:
1x front wheel complete
1x rear wheel complete
without rim tape or valves
