LIGHTWEIGHT Wheelset 28" Pathfinder EVO Disc | Clincher | BLACK ED
In order to keep control off the beaten track, you need a wheel that supports you with every movement. This is exactly why Lightweight has developed the full-carbon disc gravel wheel Pathfinder EVO. The extended tire width of up to 40 mm, in combination with the optimized layer structure, not only ensures increased precision when steering or braking, but also a significant increase in driving comfort. The Pentagon hub system and the associated braking precision make even longer descents much more comfortable and energy-saving. The pathfinder EVO is of course compatible with all common shifting systems and, thanks to the built-in DT Swiss hub, enables a quick change to different axle and freewheel standards. The well-known design of the wheels, which Lightweight has established on the market for years, ensures outstanding rigidity and durability. The full carbon spokes allow you to win every sprint, no matter how hard, circle precisely around all corners and brake with pinpoint accuracy.
The inner workings of the DT Swiss 240s hubs, which are hidden under the innovative Pentagon hub shell made of carbon, ensure smooth running and long durability. In addition to its special look, the design prevents the hub body from overheating on long descents. The SCHWARZ ED also helps you with the built-in CeramicSpeed bearings when chasing seconds.
Features:
- Extended tire width of up to 40 mm ensures more comfort on the gravel bike
- Optimized layer structure ensures significantly higher robustness.
- Use of special high-modulus CFRP fibers
- Tubeless technology
- Excellent stiffness / weight ratio
- Extremely precisely manufactured with low tolerances
- Low susceptibility to cross winds
- Pentagon hub ensures precise braking performance despite high temperatures
- Unique rolling characteristics
- Compatible with all common switching systems (Campa, SRAM, Shimano, etc.)
- Best suited for gravel, all-round, training, competition and endurance
- Simple clarity through understatement: spokes, rims and logos in black
- Greater durability and lower rolling resistance thanks to CeramicSpeed ceramic bearings
Lightweight guarantees crash replacement for all wheels!
Technical specifications:
Area of intended use : road bike, cyclocross, gravel
Wheel size: 28" (ETRTO: 622 x 18.2 mm)
Rim Type: Clincher (clincher and folding)
Brake type: only for disc brake
Brake disc mount: Centerlock (2x 6-hole adapter included)
Material: carbon, aluminum, steel
Inner width: 18.2 mm
External width: 24mm
Rim Height: 36mm
recommended valve length: 60 mm
Number of holes: -
Hubs: DT Swiss 240s
Axle standard front: 12x100 mm thru axle type
Axle standard rear: 12x142 mm thru axle type
bearing front: 2x industrial bearings
Bearing rear: 4x industrial bearing
Gasket: Labyrinth rubber gaskets
Freewheel Compatibility: 12-speed SRAM XDR; 11-, 12-speed Shimano Road; 11-, 12-speed Campagnolo; 13-speed Campagnolo N3W
Freewheel type: 2 toothed discs, 18 detents
Spokes: Carbon 20 front / 20 rear
tubeless capable: yes
recommended tire width: up to max. 40 mm
maximum system weight: 120 kg (rider incl. bike, clothing and luggage)
maximum air pressure: 25 mm - 8 bar | 28 mm - 7 bars | 32mm - 6 bars | 40mm - 5 bars
Finish: UD carbon
Colour: carbon black
Weight according to the manufacturer: 1430g (670g VR, 760g RW)
Weight weighed: 1399g (653g VR, 746g RW)
Scope of delivery:
1x wheelset Wegweiser EVO Disc | clinchers | BLACK ED
1x Lightweight double wheel bag
2x DT-Swiss 6-hole brake disc adapter
2x lightweight tubeless valves | 60mm long
2x Lightweight tire levers
1x instructions
