HOPE Pedals Union Clip Pedal RC | Race clip
Beautiful CNC-milled pedals from the milling specialists from Barnoldswick.
Hope has a suitable pedal for all XC racers. The pedal body, carved out of the full block, rotates around a light axle made of titanium and is kept small and compact in favor of the low weight. The titanium axle not only saves weight, but is just like the click mechanism and the cleats made of stainless steel, insensitive to external influences. bearing taken over from the F20 pedal is effectively shielded from the elements by special seals. Water and dirt that can lead to premature bearing wear have no chance of getting inside! 3 deep groove ball bearings and a self-lubricating slide bearing ensure smooth and easy running.
Two versions of the cleats are available: You can choose between 4 ° freedom of movement / 12 ° release angle or 5 ° freedom of movement / 13 ° release angle. Both cleats have a side play of 2 mm so that your foot is always optimally positioned.
So that the pedals match your bike optically, they are available in 6 different anodized colors. The logos are lasered, typical for Hope.
Technical specifications:
intended use : MTB XC, Gravel
Material pedal axis: titanium
Material pedal body: aluminum, CNC milled
Material click mechanism: stainless steel
Bearings: Sealed industrial / plain bearing combination
Freedom of movement: 4 ° or 5 ° (depending on the cleat)
Release angle: 12 ° or 13 ° (depending on the cleat)
Release hardness: adjustable
Q factor / axis length: 55 mm
Compatibility sole: Shimano SPD (MTB)
Compatibility pedal plate: Hope MTB Cleat
Weight Limit: -
Colors: black, silver, red, purple, orange, blue
Weight according to the manufacturer: 324g
Weight weighed: 323g
Scope of delivery:
1x pair of HOPE pedals Union Clip Pedal RC | Race clip
1x pair of cleats 4 ° freedom of movement / 12 ° release angle
1x pair of cleats 5 ° freedom of movement / 13 ° release angle
