Description
GEMINI Pröpus XC stem and handlebar unit UD carbon matt | 740 mm
Ultra-light stem and handlebar unit made in Spain
The developers of GEMINI have always been surrounded by bicycles since their early youth and are now applying their acquired knowledge about the production of composite materials, which results from years of experience in the design of motorcycles, bicycles and components, with great perfection.
The result is a stem and handlebar unit in a unibody design that is not comparable to a conventional handlebar. The ultra-light PRÖPUS was specially designed for cross country riders who focus on low weight, the best possible climbing properties, high stiffness values and maximum integration and control during technical descents.
During the development, every area of the handlebar was examined and optimized at the highest level. Compared to conventional stem / handlebar combinations, greater damping of vertical shocks and vibrations could be achieved, which leads to less fatigue of the arms and hands and enables higher speeds on descents.
On the other hand, the unibody design generates a high level of horizontal rigidity, which makes the steering much more direct and responsive.
The PRÖPUS consists of the best carbon fiber currently available on the market - Mitsubishi MR70. It was specially developed for the most demanding customers in the aerospace industry and is the key to greater comfort and safety. Countless tests in the laboratory and in the field confirm the perfect symbiosis of design and material, which offers optimal conditions for racing.
Technical specifications:
intended use : cross country, marathon
Material: Mitsubishi MR70 carbon
Handlebar clamp: integrated (unibody design)
Handlebar width: 740 mm
Rise: 0 mm
Backsweep: 7 °
Upsweep: 5 °
Offset: -12 mm
Stem length: 50 mm, 60 mm, 70 mm, 80 mm, 90 mm or 100 mm
Steerer diameter: 1 1/8 "
Clamping height of fork shaft: 29.5 mm
Can be shortened: yes, to 630 mm
Barend compatible: no information from the manufacturer
Max. Driver weight: 90 kg
Max. Tightening torque: 7 Nm stem | 2 Nm brake and shift lever | 1 Nm ahead cap
Finish: UD carbon, matt
Color logos: white
Weight according to the manufacturer: from 149g
Weight weighed: 161g (80 mm)
Scope of delivery: 1x GEMINI Pröpus XC stem-handlebar unit UD carbon matt | 740 mm
