Description
EXTRALITE front hub CyberFront SPD-3 Road Disc | 12x100 mm thru axle
It has long been known that the Italians create small CNC works of art around Extralite. With this new evolutionary level of cyberhubs, they have outdone themselves again. The now one-piece hub body is CNC-machined from high-strength 7075TX aluminum. This revolves around a further enlarged 15 mm aluminum axle with double sealed deep groove ball bearings. The axial play can be fine-tuned using the micro-tuner. The improved flange geometry ensures an optimal spoke angle and can now be used with higher spoke tensions. In addition, the assembly and servicing of wheels is made easier, since the axle no longer has to be removed for spokes.
The cyber hubs were designed for use with straight pull spokes. Advantages are a better distribution of the loads due to the disc brake, a somewhat stiffer wheel and the minimization of spoke breaks. All the use of Italian brain fat results in a 66g light disc hub with 6-hole mount , which lets the technically-minded racing cyclist & crosser fold the jaw down.
We would be happy to make you an offer for a complete custom wheelset with hubs and spokes of your choice. Please send us an email to [email protected] !
Technical specifications:
intended use : road bike, cyclocross
Material: aluminum 7075TX
axle type : 12x100 mm thru axle
Number of holes: 24
Brake disc mount: 6-hole (IS2000)
bearing : 2x deep groove ball bearings, ABEC5, 2RS sealed
Spoke type: Straightpull spokes (spoke with straight head)
Max. permissible spoke tension: kA
maximum system weight: not specified (driver, bike, clothing and possibly luggage)
Color: black anodized with laser logo
Weight according to the manufacturer: 66g
Weight weighed: 66g
Scope of delivery: 1x EXTRALITE front hub CyberFront SPD-3 Road Disc | 12x100 mm thru axle
