Description
ENVE Wheelset 29" M630 | Chris King Center Lock Hubs | Boost
ENVE products have seen a rapid rise in the cycling world. They have even been tested on major tours such as the Tour de France or the Vuelta in Spain. The carbon specialists from the USA only develop the best add-on parts without compromise for professionals and other committed cyclists.
Regardless of whether you are a cross-country racer or a trail fan, the versatile M630 wheelset with its wide intended use of uses is very popular in the bike scene. It offers enough space for voluminous tires, sits comfortably back on the scales, can be controlled precisely and still offers sufficient comfort. Together with the Chris King hubs and the Sapim spokes you will have a lot of fun with it.
Rims ENVE M630
The M630 rim is made for the current, versatile generation of mountain bikes. When climbing, it impresses with massive traction and acceleration and when going downhill with its absolutely precise, controlled handling - in combination with strong vibration and shock absorption. With the extra wide hookless rim flanges, which significantly increase puncture protection, it generates an uncompromising tire-trail interface.
ENVE carbon rims are developed by ENVE in the USA and manufactured to the highest quality standards at the headquarters in Utah. The ENVE engineers have years of experience with the use of carbon in the field of cycling and know what requirements a top product like these carbon rims must meet. At ENVE, everything is done to use the advantages of carbon and to eliminate its disadvantages. Stiff and extremely light rims were developed in which all fibers can run without interruption, which corresponds to the best possible utilization of the material strengths. This principle was perfected in the spoke holes, in which continuous fiber strands form the mount for the spoke nipples. Aluminum inserts, which are common with other carbon rims, can therefore be dispensed with during production. This reduces the weight and at the same time allows much higher spoke tensions, which in turn allow the construction of stiffer wheels!
Hubs Chris King Center Lock
There is a certain myth attached to CHRIS KING hubs. They have been on the market almost unchanged for years and yet they are not old-fashioned. Thanks to the proven technical inner workings, constant further development in detail and unmistakable optics, they have developed into a true cult object.
The unmistakable sound of the freewheel is the hallmark of the rear wheel hubs. Described by Chris King himself as the "Angry Bee Sound", the sound of the angry bee, which is generated by the 72 grid points of the stainless steel toothed disc. With this 3-part RingDrive™ system, every step is immediately converted into propulsion without much idle travel.
Due to the large hub flange, shorter spokes can be used when building wheels. This not only saves weight, but also enables a very stable and durable wheel.
The heart of the hub are the ball bearings. These are also developed and produced directly by Chris King. This means that they can be fully adapted to the specific loads and forces. Due to the multiple seal, the ingress of water or dirt is almost impossible. Before installation, each bearing is checked by hand for any quality defects and sorted out if necessary. Adjusting the bearing clearance is very simple and can also be carried out when installed. With the help of the Chris King hub tool set, which can be purchased as an option, replacing the bearings and maintaining the hub is child's play.
Spokes Sapim CX-Ray
Sapim CX-Ray spokes are so-called knife spokes. The middle section is butted to a diameter of 1.5 mm during production and forged flat in the last step. These processes strengthen the structure and produce extremely durable spokes.
ENVE are confident in the quality of their products and offer the original purchaser a 5 year guarantee from the date of purchase. You just have to register on their website.
Technical specifications:
Area of intended use : cross-country, all-mountain, trail
Wheel size: 29" (ETRTO: 622 x 30 mm)
Rim Type: Clincher (clincher and folding)
Brake type: disc brake
Brake disc mount: Center Lock
Material rim: carbon
Number of holes: 28
Inner width rim: 30 mm
Rim Height: 26.5mm
Recommended tire width: 2.3" - 2.5"
recommended air pressure: max. 1.93 bar / 28 PSI, depending on tire width and rider weight
Axle standard front: 15x110 mm thru axle type boost
Rear axle type standard: 12x148 mm thru axle boost
Freewheel: 9-, 10-, 11-speed Shimano | SRAM MTB or 11-, 12-speed SRAM XD
recommended driver weight: kA
Color rims: black matt
Hub color: black
Weight according to the manufacturer: 1616g (complete), 723g (front wheel), 893g (rear wheel)
Weight weighed:
Scope of delivery:
1x front wheel
1x rear wheel
Tubeless conversion kit
