Description
CORE ELEMENTS Basis core ready set 1
With this basic set you give your steerer an upgrade.
A twist is enough and various core elements products disappear almost invisibly in the steerer tube.
CORE ELEMENTS base sleeve core ready
The core ready base sleeve enables you to use various core elements products in your 1 1/8" steerer tube from a length of 170 mm.
It integrates almost invisibly as a base in your steerer tube without disturbing the lines of the bike. A twist is enough and the core integrated products are firmly seated in core ready.
The function of the claw is taken over by installing the core ready system, the headset remains adjustable. The lightweight stainless steel sleeve is held in a twist-proof bayonet ring made of high-strength, UV-resistant plastic. With the counterparts small, large or city and the screw set suitable for your fork length, the sleeve is clamped in the steerer tube. To do this, the claw is removed and the sleeve with the screw and washer is inserted into the steerer tube. Then you can clamp the system in the steerer tube with the counterpart that is suitable for your fork and adjust the headset play as usual.
CORE ELEMENTS counterpart
The counterpart is the counterpart for bracing the core ready base sleeve.
CORE ELEMENTS screw set
The core screw set is required to clamp the core ready base sleeve with the counterpart that fits your fork in the steerer tube.
Here you can find all core elements products.
Technical specifications:
Material sleeve: aluminium, high-strength plastic, steel
Material counterpart: high-strength plastic, aluminum
Material screw: steel
Compatibility fork: 1 1/8"
Diameter sleeve: 22.5 mm
Inside diameter sleeve: 20.5 mm
Sleeve length: 156 mm
Screw length: 20 to 100 m
Screw thread: M6
Tool holder screw: 5 mm hexagon socket
Color: silver, black
Weight according to the manufacturer: kA
Weight weighed: 94g (sleeve + counterpart small + screw set S)
Scope of delivery:
1 x core ready sleeve
1 x counterpart city, small or large
1 x screw set S, M or L
