Cane Creek headset 40.EC30/25.4 | EC30/26 1"
Cane Creek's 40 series sets the standard for durability, value and performance. Derived from the 110 series, the product range brings together all the necessities for uncompromising functionality - durable and lightweight.
Technical data:
Material: 6061 T-6 aluminum (housing, cap), steel
Construction: ahead, EC (External Cup)
Steerer tube: 1"
S.H.I.S. top section: EC30/25.4
S.H.I.S. lower part: EC30/26
Press-in dimension top Ø: 30 mm
Press-in dimension bottom Ø: 30 mm
Outer diameter top: -
Outer diameter bottom: -
Installation height top: 16 mm
Overall height bottom: 12 mm
Bearing: burnished industrial angular contact ball bearing, double sealed
Color: black
Weight according to manufacturer: 89g
Weight self-weighed: 79g
Scope of delivery: 1x Cane Creek headset incl. Ahead cap
