Description
Cane Creek tax rate 110.EC34 / 28.6 | EC34 / 30 1 1/8 "
Cane Creek's engineers were charged with the development of an uncompromising and premium premium tax rate. With the introduction of the 110 series, this order has been successfully completed - optimum material selection and unrestricted functionality paired with aesthetic design.
Technical specifications:
Material: 7075 T-6 Aluminum (housing, covers), stainless steel (ball bearing)
Construction type: ahead, EC (External Cup)
Fork shaft: 1 1/8 "
SHIS shell: EC34 / 28.6
SHIS bottom: EC34 / 30
Press-in size above Ø: 34 mm
Press-in size below Ø: 34 mm
Outside diameter: 47 mm
Outside diameter: 47 mm
Height above: 16 mm
Height below: 12 mm
bearing : Industrial angular ball bearing, double sealed
Color: black Silver | Blue | Red | gold
Weight: 113g (including head cap and claw)
Scope of delivery: 1x Cane Creek control set including head cap and claw
