ALCHEMIST rim 28" Pro Training RH38 Disc UD-Carbon matt | 24 hole
The alchemists searched for the philosopher's stone in order to be able to produce gold. As we know today, this was a foolish and never achievable endeavor. As a producer of bicycle parts, Alchemist has similarly lofty goals, but unlike its medieval predecessors, it achieves them.
Alchemist Pro Training carbon rims are manufactured in Italy. Toray T700 UD carbon fibers serve as the base material. These are held in shape by an unbreakable nanopolymer synthetic resin, which is also used in Formula 1 cockpits, resulting in a strong, torsionally rigid rim. The high impact resistance is achieved by the special Impact Perfomance (IP) processing of the fibers. This prevents delamination of the layers and thus also resists punctual impacts from the outside. Technical details such as reinforced spoke holes, hybrid rim flanges and a 38 mm high asymmetric aero profile leave no potential untapped.
Hybrid rim profile
Hybrid is a concept of hooked rims for road bikes and gravel rims. The hook on the rim flanges is much smaller than on conventional designs. This enables greater compatibility between tires and rims. In addition, the stability of the tread is increased in the event of punctures. Thanks to the newly developed production process, subsequent machining by milling and the use of additional carbon fiber layers are unnecessary.
Pro Training series
Thanks to its all-round properties and minimal weight, this series is just as suitable for everyday use as it is for training and competitions.
Technical data:
Area of application: road bike, gravel, cyclocross
Material: UD-Carbon T700
Rim type: clincher (clincher and folding tires)
Brake type: for disc brakes only
ETRTO: 622x19.5
ERD: n.a.
Inner width: 19.5 mm
Outer width: 25.1 mm
Rim height: 38 mm
Offset: 3.0 mm (asymmetrical)
Number of holes: 24 holes
tubeless compatible: yes
ASTM classification: n/a
recommended tire width: 23-32 mm | 0.9"-1.25"
maximum tire pressure: 6.5 bar - 90 PSI (25 mm), 5.5 bar - 80 PSI (28 mm), 4.5 bar - 65 PSI (32 mm)
maximum rider weight: 100 kg
maximum spoke tension: max. 1200N
Features: hybrid rim profile
valve hole: 6 mm (SV)
Finish: UD carbon matt
Color: black
Weight according to manufacturer: 344g
Weight weighed: 393g
Scope of delivery: 1x ALCHEMIST rim 28" Pro Training RH38 Disc UD-Carbon matt | 24 holes
Note: not suitable for latex tubes!
